2.92mm Female to 2.92mm Female Stainless Steel Adapter, 4-hole Flange, 40GHz
SKU:
P/N:MKJ-MKJ-SFL-02
The 2.92mm Female to 2.92mm Female Stainless Steel Adapter is perfect for interconnection of coaxial components or sub-systems connection. This 50 ohm adapter has a straight body. Our 2.92mm Female to 2.92mm Female Stainless Steel Adapter is Stainless Steel Plated that is cost-effetive for use. ZOMWAVE adapter has excellent VSWR performance with frequency up to 40GHz.
DPDT Electromechanical Relay Latching Switch, Unterminated DC to 40 GHz, up to 10W, 12V, TTL(H), 2.92mm Female Type
SKU:
P/N:SWSDP-MK40G12V-L3J1-01
The SWSDP-MK40G12V-L3J1-01 is a Double Pole Double Throw (DPDT) electromechanical relay switch that operates across a wide frequency range of DC to 40 GHz and can handle up to 10W of average power in a break before make condition. The design is rated for 2.5 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 1.0 dB insertion loss and isolation greater than 55 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mm Type female connectors and 2*5P JTAG for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP6T Electromechanical Relay Latching Switch, Unterminated DC to 12.4 GHz, up to 170W, 12V, TTL(H), N Female Type
SKU:
P/N:SWS6T-NC12G12V-L3D5-01
The SWS6T-NC12G12V-L3D5-01 is a Single Pole Six Throw (SP6T) electromechanical relay switch that operates across a wide frequency range of DC to 12.4 GHz and can handle up to 170W of average power in a break before make condition. The design is rated for 2 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.5 dB insertion loss and isolation greater than 80 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports N Type female connectors and D-sub 15pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP6T Electromechanical Relay Latching Switch, Unterminated DC to 40 GHz, up to 5W, 12V, TTL(H) , 2.92mm Female Type
SKU:
P/N:SWS6T-MK40G12V-L3D9-01
The SWS6T-MK40G12V-L3D9-01 is a Single Pole Six Throw (SP6T) electromechanical relay switch that operates across a wide frequency range of DC to 40 GHz and can handle up to 5W of average power in a break before make condition. The design is rated for 2.5 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.9 dB insertion loss and isolation greater than 55 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mm Type female connectors and D-sub 9pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP5T Electromechanical Relay Normal Open Switch, Unterminated DC to 40 GHz, up to 5W, 12V, TTL(H), 2.92mm Female Type
SKU:
P/N:SWS5T-MK40G12V-N1D9-01
The SWS5T-MK40G12V-N1D9-01 is a Single Pole Five Throw (SP5T) electromechanical relay switch that operates across a wide frequency range of DC to 40 GHz and can handle up to 5W of average power in a break before make condition. The design is rated for 2.5 million lifecycles and features a Normal Open Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.9dB insertion loss and isolation greater than 55 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mm Type female connectors and D-sub 9pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP4T Electromechanical Relay Latching Switch, Unterminated DC to 40 GHz, up to 5W, 12V, TTL(H), 2.92mm Female Type
SKU:
P/N:SWS4T-MK40G12V-L3D9-01
The SWS4T-MK40G12V-L3D9-01 is a Single Pole Four Throw (SP4T) electromechanical relay switch that operates across a wide frequency range of DC to 6 GHz and can handle up to 5W of average power in a break before make condition. The design is rated for 2.5 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.9 dB insertion loss and isolation greater than 90 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mm Type female connectors and D-sub 9pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP3T Electromechanical Relay Latching Switch, Unterminated DC to 40 GHz, 5W, 12V,TTL(H), 2.92mm Female Type
SKU:
P/N:SWS3T-MK40G12V-L3D9-01
The SWS3T-MK40G12V-L3D9-01 is a Single Pole Three Throw (SP3T) electromechanical relay switch that operates across a wide frequency range of DC to 40 GHz and can handle up to 5W of average power in a break before make condition. The design is rated for 2.5 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.9 dB insertion loss and isolation greater than 55 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mm Type female connectors and D-sub 9pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP8T Electromechanical Relay Latching Switch, Terminated DC to 40 GHz, up to 5W, 12V, TTL, 2.92mm Female Type
SKU:
P/N:SWL8P-MK40G12V-L3D5-01
The SWL8T-MK4G12V-L3D5-01 is a Single Pole Eight Throw (SP8T) with terminated electromechanical relay switch that operates across a wide frequency range of DC to 40GHz and can handle up to 5W of average power in a break before make condition. The design is rated for 2 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 1.1 dB insertion loss and isolation greater than 50 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mmType female connectors and D-sub 15pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP6T Electromechanical Relay Latching Switch, Terminated DC to 40 GHz, up to 5W, 12V, TTL(H), 2.92mm Female Type
SKU:
P/N:SWL6T-MK40G12V-L3D5-01
The SWL6T-MK40G12V-L3D5-01 is a Single Pole Six Throw (SP6T) electromechanical relay switch that operates across a wide frequency range of DC to 40 GHz and can handle up to 5W of average power in a break before make condition. The design is rated for 2.5 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.9 dB insertion loss and isolation greater than 55 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports 2.92mm Type female connectors and D-sub 15pin for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
10dB Fixed Attenuator, N Male to N Female, 25Watts, DC-18 GHz, VSWR<1.45
SKU:
P/N: ATT25W10-18-NCJ-NCP-98
10dB Fixed Attenuator, N Male to N Female, 25Watts, DC-18 GHz, Round, VSWR<1.45
SKU:
P/N: ATT25W10-18-NCJ-NCP-99
10dB Fixed Attenuator, N Male to N Female, 20Watts, DC-18 GHz, Round, VSWR<1.45
SKU:
P/N: ATT20W10-18-NCJ-NCP-99
