The SMA Male to Female Adapter offers a reliable right-angle solution for interconnecting coaxial components or subsystems. This 50 ohm SMA to coax adapter features a durable stainless steel body and ensures cost-effective performance in demanding applications. Designed with a straight body style, the ZOMWAVE adapter delivers excellent VSWR characteristics and stable signal transmission across frequencies up to 26.5GHz. Ideal for RF and microwave systems, this SMA male to female adapter meets the requirements of professional communication, aerospace, and test equipment installations with high repeatability and mechanical strength.
Key Specifications
| Configuration | |
| Adapter Series 1 | Type N |
| Adapter Gender 1 | Male |
| Impedance 1 | 75Ω |
| Adapter Mount Method1 | None |
| Body Materials and Plating 1 | Stainless Steel |
| Adapter Series 2 | SMA |
| Adapter Gender 2 | Male |
| Impedance 2 | 50Ω |
| Adapter Mount Method 2 | None |
| Body Materials and Plating 2 | Stainless Steel |
| Adapter Angle | Straight |
| Electric Specifications | |
| Frequency Range(From DC) | 6GHz |
| VSWR | To be defined |
| Insertion Loss | 5.90dB±0.5dB Max |
| Voltage Rating | 335 V(rms) |
| Dielectric Withstanding Voltage | 500 V |
| Insulation Resistance | ≥500 Mohm |
| Mechanical Characteristics | |
| Mating Cycles | ≥ 500 cycles |
| Mating Torque | 5~7 in - lbs |
| Environmental Characteristics (RoHS Complliant) | |
| Temperature Rating | -45°C ~ +125°C |
| Corrosion (Salt Spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D, 20 Gs |
| Shock | MIL-STD-202, Method 213, Condition I, 100 Gs |
| Thermal Shock | MIL-STD-202, Method 107. Cond. B, -40°C to +85°C |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
