SP6T Electromechanical Relay Latching Switch, Unterminated DC to 8 GHz, up to 210W, 24V, Positive Common, N Female Type
SKU:
P/N:SWS6T-NC08G24V-L3J2-01
The SWS6T-NC08G24V-L3J2-01 is a Single Pole Six Throw (SP6T) electromechanical relay switch that operates across a wide frequency range of DC to 8 GHz and can handle up to 210W of average power in a break before make condition. The design is rated for 1 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.35 dB insertion loss and isolation greater than 70 dB. This switch requires +24Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports N Type female connectors and 2*8P JTAG for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP6T Electromechanical Relay Latching Switch, Unterminated DC to 8 GHz, up to 210W, 12V, TTL(H), N Female Type
SKU:
P/N:SWS6T-NC08G12V-L3D5-01
The SWS6T-NC08G12V-L3D5-01 is a Single Pole Six Throw (SP6T) electromechanical relay switch that operates across a wide frequency range of DC to 8 GHz and can handle up to 210W of average power in a break before make condition. The design is rated for 1 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.35 dB insertion loss and isolation greater than 70 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports N Type female connectors and D Sub 15 for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP6T Electromechanical Relay Latching Switch, Unterminated DC to 3 GHz, up to 350W, 24V, Positive Common, N Female Type
SKU:
P/N:SWS6T-NC03G3V-L3J2-01
The SWS6T-NC03G3V-L3J2-01 is a Single Pole Six Throw (SP6T) electromechanical relay switch that operates across a wide frequency range of DC to 3 GHz and can handle up to 350W of average power in a break before make condition. The design is rated for 1 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.25 dB insertion loss and isolation greater than 80 dB. This switch requires +24Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports N Type female connectors and 2*8P JTAG for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
SP6T Electromechanical Relay Latching Switch, Unterminated DC to 3 GHz, up to 350W, 12V, TTL(H), N Female Type
SKU:
P/N:SWS6T-NC03G12V-L3D5-01
The SWS6T-NC03G12V-L3D5-01 is a Single Pole Sixt Throw (SP6T ) electromechanical relay switch that operates across a wide frequency range of DC to 3 GHz and can handle up to 350W of average power in a break before make condition. The design is rated for 1 million lifecycles and features a Latching Actuator where the selected position remains active with constant voltage, all positions are open when voltage is removed. Impressive typical performance includes 0.25 dB insertion loss and isolation greater than 80 dB. This switch requires +12Vdc bias voltage and operates over a temperature range of -25°C to +65°C. The rugged and compact package assembly supports N Type female connectors and D-SUB 15P for DC control. And for highly reliable operation, the model is guaranteed to meet MIL-STD-202 environmental test conditions for shock and random vibration.
40dB Fixed Attenuator, N Male to N Female, 100Watts, DC-18 GHz, VSWR<1.45
SKU:
P/N: ATT100W40-18-NCJ-NCP-98
ZOMWAVE coaxial 50 Ohm attenuator is manufactured to precise RF / microwave industry specifications. ATT100W40-18-NCJ-NCP-98 is N coaxial fixed attenuator operating DC to 18 GHz and rated for 100 Watts. Available from 6 to 60 dB. RoHS Compliant. ISO Certified. Shipped in 10days with small quantities.
40dB Fixed Attenuator, N Male to N Female, 100Watts, DC-18 GHz, Rectangular, VSWR<1.45
SKU:
P/N: ATT100W40-18-NCJ-NCP-99
ZOMWAVE coaxial 50 Ohm attenuator is manufactured to precise RF / microwave industry specifications. ATT100W40-18-NCJ-NCP-99 is N coaxial fixed attenuator operating DC to 18 GHz and rated for 100 Watts. Available from 6 to 60 dB. RoHS Compliant. ISO Certified. Shipped in 10days with small quantities.
40dB Fixed Attenuator, N Female to N Female, 50Watts, DC-18 GHz, Round, VSWR<1.45
SKU:
P/N: ATT50W40-18-NCJ-NCJ-99
40dB Fixed Attenuator, N Male to N Female, 50Watts, DC-18 GHz, Round, VSWR<1.45
SKU:
P/N: ATT50W40-18-NCJ-NCP-98
40dB Fixed Attenuator, N Male to N Female, 50Watts, DC-18 GHz, Rectangular, VSWR<1.45
SKU:
P/N: ATT50W40-18-NCJ-NCP-99
40dB Fixed Attenuator, N Male to N Female, 30Watts, DC-18 GHz, Round, VSWR<1.45
SKU:
P/N: ATT30W40-18-NCJ-NCP-99
40dB Fixed Attenuator, N Male to N Female, 25Watts, DC-18 GHz, VSWR<1.45
SKU:
P/N: ATT25W40-18-NCJ-NCP-98
40dB Fixed Attenuator, N Male to N Female, 25Watts, DC-18 GHz, Round, VSWR<1.45
SKU:
P/N: ATT25W40-18-NCJ-NCP-99
